QB Series electric clean water pump are a high efficiency household electric pump, consisting of micro motor and eddy water pump adopting high quality special mechanical seal equipment.
These pumps are designed for transfering water from water tanks not sucking water out of a pit or well
Features:
- Compact construction
- Very economical, reliable, safe and easy operation and maintenance.
- High Head, steady flow and low power consumption.
- Pump has peripheral impeller containing numerous radial blades on its edge.
- Perfect for water transfer and long running jobs, this unit provides constant delivery over hours of use.
- Compact design with mountable feet is just the thing for permanent installations.
- It is designed for home use, pool pumping, garden sprinkling, irrigation and garden applications etc.
Working Condition:
- Max. medium temperature up to: +40° C
- Max. ambient temperature up to: +40° C
- Medium free from granules or anything that may damage the pump.
Specifications:
- Model: QB-70
- Frame: 71
- Power: 550W/0.75HP
- Max. Capacity (L/min): 43
- Max. Head* (m): 50
- Max. Suction (m): 9
- Speed (r.p.m): 2850
- Pump dia (mm): 25X25
- Overall Dimension (mm): 310X138X172
- Inlet/Outlet pipe size: 1 inch
- Power: Single-phase voltage 240V, frequency 50 Hz
|
 |
| QB60 |
Head* (m) |
0 |
5 |
10 |
15 |
20 |
| Qty (L/MIN) |
36 |
30 |
25 |
20 |
15 |
| |
| QB70 |
Head* (m) |
0 |
5 |
10 |
15 |
20 |
| Qty (L/MIN) |
45 |
40 |
37 |
32 |
28 |
| |
| QB80 |
Head* (m) |
10 |
15 |
20 |
25 |
30 |
| Qty (L/MIN) |
50 |
45 |
38 |
32 |
20 |
* Max head is the maximum height the pump can pump vertically. If you need to pump higher than that, we recommend that you purchase a bigger pump.
Please Note: Automatic Pressure Control Switch for this unit can be purchased seperately from our Store. |
