Warning : missing both mounting feet on either side of the motor and small crack in plastic case will supply new plastic case with sale  email for speacial discount on motor only 1 in stock

This Single Phase electric motor has a lot of advantages including: high efficiency, large starting rotor torque, excellent performance, low nose, low vibration, high reliability, convenient operation and maintenance, and the mounting dimension that meets the IEC standard, and so on.

This electric motor is fit for the common sites that contain no inflammable, explosive or corrosive gas and machineries that has no special requirements including: metal cutting machine, water pump, fan, transportation machinery, puddle mixer, agricultural machinery, foodstuff machinery, etc.

Specifications:

• Model: Y2-904-2
• Rated Output: 2HP
• 12 amps
• At full load speed 2850 rpm
• 250 µF ( 450 V)
• 240 volts
• 50 Hz
• Class B
• Shaft with keyway
• This unit comes with a 240volt Australian Standard Plug attached.

Dimensions:

• Height of Motor: 230mm
• Length of Motor including shaft: 340mm
• Shaft diameter: 24mm
• Shaft length: 50mm
• Hole feet dimensions (hole to hole):
  • 125mm (length)
  • 140mm (width)
